EXALCO SLIDING SYSTEMS
Sliding Systems
Thermal Break Systems
Opening
Sliding
Curtain Walls
Aluminum Alloy : EN AW 6060 T6 EN 15088:2005
Anodising: According to the European standard Qualanod
Gaskets: EPDM / EPDM Foam
Powder coating: According to the European standard Qualicoat
Tolerance: EN 12020-2
ALBIO 225 LS
Exalco Albio 225LS is one of Exalco’s latest technological achievements in the gliding product group. With a contemporary linear design, the system is ideal for applications with large openings, high strength profiles, and high inertia moments.
Balcony Doors
Windows
Shutters
Fly Screens
Slide
Lift & Slide
Glazing Thickness:
5-22mm
Scroll Guide:
Stainless steel, polyamide
Thermal- Break:
24mm (PA 6.6, 25%GF)
Air Permeability:
Specimen Dimensions: 1.40m X 2.20m: Class 3 (EN1026:2000 / EN 12207:2000)
Thermal transmittance coefficient:
3.1 – 5.1 W/(m2K) (EN 10077-2:2003-10)
Water Tightness:
Specimen Dimensions: 1.40m X 2.20m: Class 6A (EN1027:2000 / EN 12208:2000)
Sash dimensions:
Width 38mm, height 97mm
Resistance to wind load:
Specimen Dimensions: 1.40m X 2.20m: Class C4 (EN12211:2000 / EN 12210:2000)
The system has excellent thermal insulation properties thanks to 24 mm polyamides and special multi-chamber PVC additions. Besides, the system provides firm integrity through EPDM seals and its special lift-slide rail mechanism. These fittings allow the use of large and thick glazing, with a capacity of up to 90 kgof sash weight.
ALBIO 227
Exalco Albio 227 is a sliding system with thermalbreak, suitable to replace old sliding windows.
The triple frame (glass – mosquito net – blind) isonly 95mm wide and suitable for narrow wall openings. The door and frame profiles are equipped with 10 mm and 18 mm polyamide bars. With a sash width of 31 mm and a sash width of 28mm, Exalco Albio 227 offers the possibility of making all kinds of sliding windows.
Windows, balcony doors, successive or built-in.
Balcony Doors
Windows
Shutters
Fly Screens
Slide
Lift & Slide
Glazing Thickness:
20mm
Scroll Guide:
Stainless steel, polyamide
Thermal- Break:
18mm (PA 6.6, 25%GF)
Air Permeability:
Specimen dimensions: 1.40m X 2.20m: Class 3 (EN1026:2000 / EN 12207:2000)
Thermal transmittance coefficient:
3.7 – 4.8 W/(m2K) (EN 10077-2:2003-10)
Water Tightness:
Specimen dimensions: 1.40m X 2.20m: Class 5B (EN1027:2000 / EN 12208:2000)
Sash dimensions:
Width 31mm, height 96mm
Resistance to wind load:
Specimen dimensions: 1.40m X 2.20m: Class C1/C2(EN 12211:2000 / EN 12210:2000)
ALBIO 230 LS
Exalco Albio 230 Lift & Slide is one of Exalco’s Latest technological achievements in the sliding systems product group. Its unique design makes it ideal for wide-opening applications, having high resistance profiles and a high moment of inertia. The system has excellent thermalinsulation with 20mm polyamides and PVCprofiles. Also, the system offers tightness thanksto its special railing mechanism.
Windows, balcony doors, successive or built-in.
Balcony Doors
Windows
Shutters
Fly Screens
Slide
Lift & Slide
Glazing Thickness:
22 – 50mm
Scroll Guide:
Stainless steel, polyamide
Thermal- Break:
20-24mm (PA 6.6, 25%GF)
Air Permeability:
Specimen dimensions: 2.10m X 2.20m: Class 3 (EN1026:2000 / EN 12207:2000)
Thermal transmittance coefficient:
2.4 – 6.2 W/(m2K) (EN 10077-2:2003-10)
Water Tightness:
Specimen dimensions: 2.10m X 2.20m: Class E750 (EN1027:2000 / EN 12208:2000) Inside frame, Class 8A (EN1027:2000 / EN 12208:2000) Outside frame
Sash dimensions:
Width 69.3mm, height 95.9mm
Resistance to wind load:
Specimen Dimensions: 2.10m X 2.20m: Class C3 (EN12211:2000 / EN 12210:2000)
ALBIO 235 LS
Exalco Albio 235 Lift & Slide is ideal for wide-opening applications, having high strength profiles and a high moment of inertia. The system exhibits excellent thermal insulation properties thanks to polyamides from 24 to 34mm and notable multi-chamber PVC additions. Also, the system provides hermetic integrity thanks to the EPDM gaskets and its unique sliding rail mechanism. These fittings allow the use of large and thick windows with a capacity of up to 250 kg of sash weight.
Windows, balcony doors, successive or built-in
Balcony Doors
Windows
Shutters
Fly Screens
Slide
Lift & Slide
Glazing Thickness:
24mm & 36mm
Scroll Guide:
Stainless steel, polyamide
Lift & slide fitting:
GU-937/957
Thermal- Break:
12mm, 24mm, 34mm (PA 6.6, 25%GF)
Air Permeability:
Specimen dimensions: 2.10m X 2.20m: Class 4 (EN1026:2000 / EN 12207:2000)
Thermal transmittance coefficient:
3.6 – 6.8 W/(m2K) (EN 10077-2:2003-10)
Water Tightness:
Specimen dimensions: 2.10m X 2.20m: Class 7A (EN1027:2000 / EN 12208:2000)
Sash dimensions:
Width 56mm, height 84.5mm
Resistance to wind load:
Specimen dimensions: 2.10m X 2.20m: Class C4 (EN12211:2000 / EN 12210:2000)
ALBIO 256 LS THEA
Exalco Albio 256 Thea lift and slide system with thermal breakage
Albio 256 Thea is one of the only minimal lift and slide systems that offers an ideal seal thanks to EPDM seals.
It has a minimal appearance with the integration of the frame into the wall along the perimeter, a visible profile of 45.1 mm, and a narrow hook with a visual area of only 42 mm.
It has excellent thermal insulation properties with Uw = 1.15 W / m2K with Ug = 0.6 W / m2K.
A unique water drainage system has been studied that allows an excellent functioning of the system and gives the possibility of draining the water even from inside the system.
Balcony Doors
Windows
Shutters
Fly Screens
Slide
Lift & Slide
Glazing Thickness:
Scroll Guide:
Stainless steel, polyamide
Lift & slide fitting:
Thermal- Break:
12mm, 24mm, 34mm (PA 6.6, 25%GF)
Air Permeability:
Thermal transmittance coefficient:
Uw = 1.15 W / m2K with Ug = 0.6 W / m2K.
Water Tightness:
Specimen dimensions: 2.10m X 2.20m: Class 7A (EN1027:2000 / EN 12208:2000)
Sash dimensions:
visible profile of 45.1 mm, and a narrow hook with avisual area of only 42 mm
Resistance to wind load:
A unique water drainage system has been studied that allows an excellent functioning of the system and gives the possibility of draining the water even from inside the system. Possibility of building all kinds of lifting and sliding systems.
An essential advantage of Albio 256 Thea is that it can be used in existing structures.
ALBIO 256 S THEA
Balcony Doors
Windows
Shutters
Fly Screens
Slide
Lift & Slide
Glazing Thickness:
Scroll Guide:
Stainless steel, polyamide
Lift & slide fitting:
Thermal- Break:
12mm, 24mm, 34mm (PA 6.6, 25%GF)
Air Permeability:
Thermal transmittance coefficient:
Uw = 1.15 W / m2K with Ug = 0.6 W / m2K.
Water Tightness:
Specimen dimensions: 2.10m X 2.20m: Class 7A (EN1027:2000 / EN 12208:2000)
Sash dimensions:
visible profile of 45.1 mm, and a narrow hook with avisual area of only 42 mm
Resistance to wind load:
ALBIO 225 SLIM
Balcony Doors
Windows
Shutters
Fly Screens
Slide
Lift & Slide
Glazing Thickness:
Scroll Guide:
Lift & slide fitting:
Thermal- Break:
Air Permeability:
Thermal transmittance coefficient:
Water Tightness:
Sash dimensions:
Resistance to wind load:
ALBIO SPACE
Balcony Doors
Windows
Shutters
Fly Screens
Slide
Lift & Slide
Glazing Thickness:
Scroll Guide:
Lift & slide fitting:
Thermal- Break:
Air Permeability:
Thermal transmittance coefficient:
Water Tightness:
Sash dimensions:
Resistance to wind load:
